Step 1.  Gapping


Click The Image To Zoom In Girl looking out people on beach Automatic Metal Zipper Gapping Machine (long model)


     1-Model No.: QLQ-MGM
     2-Output: 2800PCS/60CM/H
     3-Power: 380V,50HZ,3PH,2.2KW
     4-Machine size: 1.95*0.80*1.90M
     5-Packing size: 1.40*0.90*1.80M
     6-N.W.: 420KG, G.W.: 490KG

You can find the different detailes between long model and short model from our inside solutation page.

Note: There are another 2 models you can choose: QLQ-MGM and QLQ-MDGM-2. Please see final excel form for reference.

Machine’s Link: https://www.qlqcompany.com/en/products/zm/zgw/137.html

Material's Link: http://www.qlqcompany.com/en/products/zsm2/lcz/246.html




Material's Needed:


Metal Long Chain Zipper





Step 2-1.  Bottom Stop Fixing ( Bottom Stop Wire Model )



1-Model No.: QLQ-BSM
2-Output: 4800PCS/18CM/H
3-Power: 220V,50HZ,1PH,1.2KW
4-M/C size: 1.38*0.63*1.88M
5-Packing size: 0.80*0.78*1.60M
6-N.W.: 130KG, G.W.: 180KG"

We have aluminum bottom stop model, ultrasonic bottom stop model, ultrasonic teeth melting bottom stop model for choosing.

Note: This video is   for high configuration model. Standard configuration model's function is the same..

Machine’s Link: http://www.qlqcompany.com/en/products/zm/zbsm/508.html

Material's Link: https://www.qlqcompany.com/en/products/zsa/bstsw/index.html#cplist

Click The Image To Zoom In Girl looking out people on beach Automatic Metal Zipper Bottom Stop Machine
(By Brass Bottom Stop Wire)

Material's Needed:


Brass Bottom Stop Wire

Machine’s Video:





Step 2-2.  Stop Fixing (Grain "H" Bottom Stop Model)



1-Model No.: QLQ-HBSM
2-Output: 3800PCS/18CM/H
3-Power: 380V,50HZ,3PH,1.5KW
4-Machine size: 1.30*0.68*1.90M
5-Packing size: 0.80*0.95*1.60M
6-N.W.: 150KG, G.W.: 200KG

We have aluminum bottom stop model, ultrasonic bottom stop model, ultrasonic teeth melting bottom stop model for choosing.  .

Note: This video is   for high configuration model. Standard configuraiton model's function is the same. ..

Machine’s Link: http://www.qlqcompany.com/en/products/zm/zbsm/217.html

Material's Link: https://www.qlqcompany.com/en/products/zsa/gbsats/938.html

Click The Image To Zoom In Girl looking out people on beach

Material's Needed:


Grain “H” Bottom Stop Model

Machine’s Video:





Step 3.  Slider Mounting


Click The Image To Zoom In Girl looking out people on beach Automatic Metal Zipper Slider Mounting Machine


1-model No.:QLQ-SMM
2-output:3500PCS/18CM/H
3-Power:220V,50HZ,1PH,2.2KW
4-M/C size:1.55*0.66*2.10M
5-packing size:0.92*0.76*1.50M
6-N.W.: 200KG, G.W. 245KG"

If you want this slider mounting machine can be suitable for different fancy puller, please send all samples to us, we will try to make the vibrator suitalbe for these model. .

Note: This video is for high configuration model. Standard configuraiton model's function is the same.

Machine’s Link: https://www.qlqcompany.com/en/products/zm/zsmm/670.html

Material's Link: https://www.qlqcompany.com/en/products/zsm2/slider/1382.html

Material's Needed:


                       YG Slider

Machine’s Video:





Step 4-1.  Top Stop Fixing (Top Stop Wire model)



1-model No.:QLQ-TSM
2-output:2800PCS/18CM/H
3-Power:380V,50HZ,3PH,1.5KW
4-M/C size:1.38*0.68*1.45
5-packing size:0.85*0.85*1.62
6-N.W.:135 KG, G.W.185KG"

We have aluminum top stop model and ultrasonic "U" shape  top stop model for choosing.

Note: This video is  for high configuration model. Standard configuration model's function is the same.

Machine’s Link: http://www.qlqcompany.com/en/products/zm/ztsb/447.html

Material's Link: https://www.qlqcompany.com/en/products/zsa/bstsw/929.html

Click The Image To Zoom In Girl looking out people on beach Automatic Metal Zipper Top Stop Machine (by brass top stop wire)

Material's Needed:


Brass Top Stop Wire

Machine’s Video:





Step 4-2.  Top Stop Fixing (Grain "U" Shape Model )



1-model No.:QLQ-MUTM
2-output:2500PCS/18CM/H
3-Power:220V,50HZ,1PH ,2.0KW
4-M/C size:1.38*0.75*1.50M
5-packing size:0.90*0.80*1.60M
6-N.W.: 165KG G.W. :210KG

We have aluminum top stop model and ultrasonic "U" shape  top stop model for choosing.

Note: This video is  for high configuration model. Standard configuration model's function is the same.

Machine’s Link: https://www.qlqcompany.com/en/products/zm/ztsb/449.html

Material's Link: https://www.qlqcompany.com/en/products/zsa/gbsats/936.html

Click The Image To Zoom In Girl looking out people on beach Automatic Metal Zipper Gapping Machine (long model)

Material's Needed:


Grain U Shape Top Stop

Machine’s Video:





Step 5.  Cutting


Click The Image To Zoom In Girl looking out people on beach Automatic Metal Zipper Closed-end Zigzag Cutting Machine


1-model No.:QLQ-ZCM-1
2-output:4000PCS/18CM/H
3-Power:220V,50HZ,1PH,1KW
4-M/C size:1.80*0.70*2.00M
5-packing size:0.80*0.90*1.40M
6-N.W.:200KG, G.W.260KG"

We have standard cutting machine, ultrasonic cutting machine, cutting with labour hand machine for your choosing. You can see the different details from our inside solution page.

Note: This video is  for high configuration model. Standard configuraiton model's function is the same.

Machine’s Link: http://www.qlqcompany.com/en/products/zm/zccm/892.html

Machine’s Video:







Contact Us Anytime

We will be on after-sales service for you all during the machine's whole life after you buy our machines, you can contact us anytime when there be any problems for machines. We will offer you all the machines’ technical suggestions and help you to solve the problems by video talking or e-mail and other way.

Email:

Sales@qlqcompany.com
a6@qlqcompany.com

Websites:

http://www.zippermachine.com
http://www.qlqcompany.com
